(ON) OFF (ON) Toggle Switch Flick 6 Terminal Spring Load 12V 24V Cargo 180592

METAL TOGGLE FLICK SPRING LOADED SWITCH 6 TERMINALS  12V 16A 24v CARGO

180592

Electrical specifications

• Voltage: 12
• Amp: 16
• Amp 2: 8
• Voltage 2: 24

Physical specifications

• Terminals: 6
• Switch type: ( On ) / Off / ( On )
• Mount. hole size: mm 12
• 2 poles: Yes
• Arm: Short
• Material: Metal

THIS SWITCH IS SPRING LOADED SO SITS IN THE CENTRAL OFF POSITION.
THE OTHER POSITIONS ARE MOMENTARY AND WHEN THE SWITCH IS RELEASED IT SPRINGS BACK TO THE CENTRAL OFF POSITION.

• If wired correctly this switch can be used as a changeover
• 6.3MM LUCAR TERMINALS X6
• 12 MM HOLE REQUIRED FOR FITMENT.

What do SPST, SPDT, DPST, and DPDT mean?
SP and DP refer to single pole and double pole, ST and DT refer to single throw and double throw.

Pole refers to the number of circuits controlled by the switch: SP switches control only one electrical circuit. DP switches control two independent circuits (and act like two identical switches that are mechanically linked). Do not confuse ‘pole’ with ‘terminal’. The DPST switch, for example, has four terminals, but it is a DP, not a 4P switch.

Throw refers to the extreme position of the actuator: ST switches close a circuit at only one position. The other position of the handle is Off. DT switches close a circuit in the Up position, as well as the Down position (On-On). A DT switch can also have a center position (frequently On-Off-On).

ANOTHER HIGH QUALITY HC CARGO PRODUCT ( A BOSCH GROUP COMPANY )
