45 Amp Pal Japanese Fuse Slow Blow 2935 Series Red 12V 24V 32V Cargo 191832

45 AMP PAL FUSE SLOW BLOW 2935 SERIES RED 12V 24V 32V CARGO 191832

PAL Fuse 2935 Series

191832

PAL fuses are commonly found on many Japanese and domestic built vehicles.

ELECTRICAL CHARACTERISTICS

• Voltage Rating: 32 VDC
• Current Cycling: 24˚C
• The fuses satisfy the performance requirements after 50% of the rated current
• is applied for 10,000 cycles. Each cycle consists of an interrupted current with
• the pattern of 5 minutes ON and 10 minutes OFF.
• Operating Temperature Range: -40˚C to 흮˚C
• Complies with JASO 0612

Time-Current Characteristics

• % of Rating Opening Time Min / Max (s)
• 110 14,400 s
• 200 5 s / 100 s
• 350 0.2s / 7 s
• 600 0.040 s / 1 s

ANOTHER HIGH QUALITY HC CARGO PRODUCT
( A BOSCH GROUP COMPANY)
